C350 L0 AS1163 Australian Structural Steel Pipe

Brief Overview

C350 L0 structural pipe complies with Australia’s AS1163 industrial specification, manufactured via mature JCOE cold forming to produce LSAW straight seam tubing. The C350 grade guarantees a minimum yield strength of 350MPa, while the L0 marking confirms qualified low-temperature impact resistance, making it ideal for construction projects in cold climate zones. Produced on fully automatic submerged arc welding lines, the pipe delivers consistent weld quality and efficient mass output. It is widely adopted for Australian municipal infrastructure, water and gas transportation, as well as large-scale pipeline engineering.

Full Detailed Product Description

Product Profile & Standard Background

AS1163 is Australia’s authoritative unified standard for all tubular products, covering performance inspection rules for hot-formed welded tubes, cold-formed welded pipes and seamless steel pipes. Classified as JCOE submerged arc welded pipe, C350 L0 differs structurally from high-frequency resistance welded straight seam tubes in molding techniques. Thanks to balanced tensile strength, toughness and welding performance, it has become a mainstream structural material for urban foundation construction and medium and large-scale fluid delivery pipeline projects across Australia.

Core Manufacturing Advantages

All welding procedures are completed on automated assembly lines, which avoids unstable quality caused by manual operation errors and ensures uniform performance for every pipe batch. During welding, welding flux fully covers the electric arc, isolating air to prevent weld oxidation and internal defects such as pores and cracks. Adapting high-current submerged arc welding technology greatly improves production efficiency to satisfy urgent bulk wholesale orders. Besides, the official L0 low-temperature toughness certification enables the pipe to avoid brittle fracture under subzero environments, expanding its application in alpine and coastal cold-area projects.

Complete Product Parameter Info

Dimensional Specifications

JCOE LSAW Bare Pipe: Outer Diameter 457mm–1422mm (18–56 inch), Wall Thickness 8mm–50mm, Standard Length 5800mm–12300mm Anti-Corrosion Coated Finished Pipe: Outer Diameter 219mm–1620mm, Standard Length 5800mm–12300mm, wall thickness customizable based on client demands

Optional Base Material Grades

Q235, Q345, X42, X46, X52, X56, X60, X65, X70, X80 and other mainstream pipeline steel grades

Recognized Production Standards

API Spec 5L (PSL1, PSL2), ASTM A252, ASTM A672, ISO 3183

Custom Anti-Corrosion Coating Solutions & Matching Standards

Single/Double FBE Coating follows CAN/CSA Z 245.20, DIN 30671 2LPE / 3LPE Polyethylene Coating follows CAN/CSA Z 245.21, DIN 30670 2LPP / 3LPP Polypropylene Coating follows DIN 30678, NFA49711

Factory Production Capacity

The annual steel pipe output reaches 150,000 tons. The independent anti-corrosion workshop can finish surface anti-rust treatment for 1200 square meters of steel pipes within a 12-hour working shift, supporting fast delivery for overseas orders.

Technical Standards for Different Engineering Scenarios

For building hollow frame projects, we follow standardized welding specifications including matched welding material selection and accurate welding heat input control, with full low-temperature toughness tests for finished welds. For long-span bridge bearing structures, extra fatigue resistance tests are required for welding joints, and we strictly control grain coarsening in the weld heat-affected zone to eliminate structural hidden dangers. For sites with ambient temperature below -10℃, all welding accessories need low-temperature impact qualification, and all welds will pass -40℃ Charpy impact tests to prevent cold cracking.

Practical Procurement Reference Guidance

All finished pipes strictly meet the threshold of yield strength ≥350MPa and tensile strength ≥450MPa to guarantee long-term bearing stability. For cold-region procurement, we provide official third-party low-temperature impact test reports for customs clearance and project inspection. Complete shipment documents including material component reports, mechanical test sheets and factory inspection certificates will be provided together. For coastal and humid industrial sites, customized anti-corrosion coating is strongly recommended to resist salt fog corrosion and extend pipe service life.
